Product Details
＋| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | 1SAM250000R1012 |
| Current Rating | 8-12 A |
| Enclosure Type | Open |
| Horsepower Rating | 7.5 hp@480V |
| Interrupt Rating | 25 kA@400VAC |
| Number of Poles | 3 |
| Power Rating | 5.5 kW |
| Series | |
| Special Features | Thermal and Magnetic Protection ; Phase Loss Sensitivity ; Disconnecting Feature |
| Standards | cULus ; E137861 ; CCC ; GOST or EAC ; KC ; BV ; DNV-GL ; LR ; ABS ; RMRS |
| UPC Code | 66201909156 |
| Voltage Rating | 690 V |
Overview
Manual Motor Starters
The ABB MS132 series of manual motor starters are compact highly reliable devices used to manually switch on and off motors. The MS132 series protects the motors reliably, without the need for a fuse, from short-circuits, overload and phase failures.
